Product Introduction:
Main Features and Advantages of the Slanted-Bracket Permanent Derrick: The single-braced derrick, developed with the development of floor-standing multi-rope surface drilling technology, features a unique design, simple structure, optimal load-bearing, minimal engineering effort, and economical, practical, and technologically advanced design.
Product Introduction:
Main Features and Advantages of the Slanted-Bracket Permanent Derrick: The single-braced derrick, developed with the development of floor-standing multi-rope surface drilling technology, features a unique design, simple structure, optimal load-bearing, minimal engineering effort, and economical, practical, and technologically advanced design.
| Heading | model | Applicable wellbore depth（m） | Height from foundation to sky wheel platform（m） | Derrick leg span（m） | Sheave platform size（m） | weight（t） |
| Well Drilling Steel Pipe Derrick | Ⅰ | 200 | 16.24 | 10×10 | 5.5×5.5 | 25.09 |
| Ⅱ | 400 | 17.25 | 12×12 | 6.0×6.0 | 30.62 | |
| Ⅲ | 600 | 17.35 | 12×12 | 6.5×6.5 | 33.07 | |
| Ⅳ | 600 | 19.85 | 12.83×12.83 | 6.5×6.5 | 39.47 | |
| Ⅴ | 800 | 21.91 | 14×14 | 7.0×7.0 | 49.37 | |
| Ⅵ | 800 | 25.87 | 15.3×15.3 | 7.0×7.0 | 58.54 | |
| Ⅶ | 1000 | 26.36 | 16×16 | 7.5×7.5 | 72.37 | |
| Ⅷ | 27.08 | 17.5×17.5 | 9.05×9.05 | 98 |
